Product PDF

HID RFID Cards and Readers

HID RFID Readers

  • More powerful and versatile access control

  • User-friendly proximity technology

  • Uses the 13.56 MHz technology platform

  • High-intensity, three-color light bar provides clear, visual feedback, even in direct sunlight

  • Selectable, distinct tone sequences indicate status conditions

  • All RF data transmission between the card and reader is encrypted using a secure algorithm

  • Close range

HID RFID Cards

  • Offer sufficient read/write memory to store multiple biometric templates

  • Available in a two- or 16- application-area configuration

  • Offer multiple, securely separated areas to enable numerous applications, including the HID standard access control application

  • Future growth for new read/write applications

  • ISO 15693 and 14443B2 standards for read/write contactless communication

  • Cost-effective way to enhance the security of your access control installation

  • Close range

Request More Information
Tags

Power Supply:
10 to 16 VDC reverse voltage protected
Linear supply recommended

Read Range*:
2.5 to 4.5 in (6.3 to 11.4 cm) with HID iCLASS® card
1.0 in (2.5 cm) with HID iCLASS key
1.0 in (2.5 cm) with HID iCLASS tag
1.5 to 2.0 in (3.8 to 5.0 cm) with HID iCLASS prox
1 to 2 in (2.5 to 5.0 cm) with MIFARE® card
(serial number only)


*Using ISO 15693 mode (except MIFARE®). Dependent upon installation conditions. Please note that all iCLASS credentials are available in either a 2K bits (256 Bytes) or 16Kbits (2 KBytes) configuration.

Transmit Frequency:
13.56 MHz

Current Requirements (Avg/Peak):
80/260mA at 12 VDC

Material:
UL94 polycarbonate

 Cable Distance:
Wiegand interface: 500 ft (150 m)
Recommended cable is ALPHA 1295 (22AWG)
Five-conductor stranded with overall shield or equivalent. Additional conductors may be required to connect all outputs.

Dimensions:
(L × W × H)
3.30 × 0.85 × 4.80 in
(84 × 22 × 122 mm)

Temperature:
Operating: -31 to 150 °F (-35 to 65 °C)

Humidity:
5 to 95% RH non-condensing

Weight:
8.8 oz (249.5 g)

Pending Certifications:
Taiwan, Singapore, Germany VdS

Approvals:
UL 294/cUL
FCC Certification
Canada Certification
CE Mark (Europe)
New Zealand
Australia c-Tick

Resources/Downloads

Title View Email Category Type
Rattling Acres View Email Truck Scales|Indicator Software|Indicators / Controllers|Vehicle Scale Accessories Application Story|Articles

Title Download Email
HID RFID Cards and Readers Catalog Page Download Email

Title Version Revision Download Email Category Archived
HID Reader/Interface Board Installation B Download Email Onboard Weighing|Vehicle Scale System No

Parts

HID RFID Readers

Part # Description List Price Cart/Quote
176452 Reader,HID Smart Card Assembly Includes Wiegand to RS232 Converter and Mounting Hardware (Replacement for part 85901)

List Price: $695.00
88792 Power Supply,IDEC 12VDC DIN Rail Mount, 1.3 Amp, Input: 85 to 264 VAC, 100 to 370 VDC 15W

List Price: $140.00
85902 Contactless,Smart Card 25 Pack, Numbered 1-25, HID, 13.56MHz, 26-Bit, H10301 Format, Facility Code 001 Internal Card Number And External Printed Number Match

List Price: $255.00
85903 Contactless,Smart Card 25 Pack, Numbered 26-50, HID, 13.56MHz, 26-Bit, H10301 Format, Facility Code 001 Internal Card Number And External Printed Number Match

List Price: $255.00
85904 Contactless,Smart Card 25 Pack, Numbered 51-75, HID, 13.56MHz, 26-Bit, H10301 Format, Facility Code 001 Internal Card Number And External Printed Number Match

List Price: $255.00
85905 Contactless,Smart Card 25 Pack, Numbered 76-100, HID, 13.56MHz, 26-Bit, H10301 Format, Facility Code 001 Internal Card Number And External Printed Number Match

List Price: $255.00
95358 Card,HID Unprogrammed Configured 256 Byte No Slot Punch - MUST BE FACTORY PROGRAMMED

List Price: $15.00
212168 Card,HID Unprogrammed Configured 256 Byte Vertical Slot

List Price: $15.00
